Exact scoring. Shot after shot

TrueScore10 Electronic Scoring Target – DSB and ISSF certified

TrueScore10 electronic scoring target is a revolution in how the sports shooting industry is detecting and scoring hits. The target is DSB and ISSF certified! The optical measurement frame ensures exact hit scoring, giving the user true confidence in each shot measured. The target is designed for 10 and 15-meter shooting distances for air pistols and air rifles.

DSF and ISSF certified

Easy to clean bullet trap, producing uniform projectile chips with little dust

Built-in TFT display for a traffic light or displaying the last hit position

No parallax errors

Effortless range setup, low operating costs, no consumables and servicing

Revolutionary scoring technology with a superior hit accuracy of below 100 microns

Watch the video and find out more about TrueScore10 Electronic Scoring Target

Transparency to scoring and fair competition

Our industry-leading optical measurement technology provides exact, parallax-free scoring across the entire target area. With Truescore10 you can always be confident that the result shown on the shooters' monitor is absolutely true to what you have actually scored.

Integrated TFT display

"Use the target without the shooter's monitor. The display shows the score and acts as a green/red light signal for 10m timed pistol disciplines. It also assists during shooting range lane setup to quickly assign monitors to the right target number."

Adjustable LED frame light

Avoid eye strain during long training hours. Adjust the brightness of the aiming card to match the surrounding light conditions. Quickly reset the target to comply with ISSF and DSB competition rules using the built-in presets.

Magnetic front panel and aiming card lock

No more latches - quick and easy change of aiming cards and access to target internals. The magnetic lock holds the aiming card securely in place and avoids any displacement.

System includes

\- Target frame
- Bullet catcher
- INTARSO software
- Cable to connect to the owner’s PC

Optional equipment

\- Black paper roll (comes in the competition package)
- Target stand

Downloads

- Datasheet

Hardware Specification

Target frame with detection area: 17 x 17 cm
Shooting distances: 10 and 15 meters
Mounting option: wall mount or stand mount
Supported weapons: air pistol, air rifle

Designed for use at sports clubs and international competitions

TrueScore10 electronic scoring target was designed for sports clubs and international shooting competitions. The target system can be easily adjusted to any training and competitive scenario. For use at a competition, a black roll can be added to the target system.

FOR CLUBS

Target frame
Bullet catcher

FOR COMPETITIONS

Target frame
Bullet catcher
Black roll

TrueScore10 electronic target comes with the most versatile electronic scoring software in the market.

SOFTWARE SPECIFICATION

Different software packages to meet the individual shooter or club requirements,
Web-based, compatible with any modern web browser
Supports different devices and screen sizes
Compatible with Windows, Linux, macOS
Supports targets and disciplines from ISSF, DSB, BDS
Individual user profiles and access to personal training history

Effortless and Fast Range Setup

"TrueScore10 provides versatile network configuration options - hard-wired Ethernet, Wi-Fi and hybrid.

The core of the network is the TrueScoreTM server, which runs the ESA software. The target devices and shooter monitors communicate directly to the server. That provides all management options for the shooting range administrator. The options include device mapping, lane assignment and other important network configuration options."

Effortless and Fast Range Setup

"The most reliable network configuration. In this case, all targets, shooter monitors and networking equipment are connected using hard-wired Ethernet cables. This is the preferred option for fixed installation shooting ranges, shooting competitions and ranges with 5+ lanes as this configuration provides the ultimate network performance and reliability."

Hybrid (Ethernet / Wi-Fi)

"A robust, yet convenient alternative to the pure hard-wired Ethernet network is to connect your target devices via Ethernet, but for the shooter, monitors use a Wi-Fi connection. Such an option enables the possibility to quickly change the shooting distance as you can easily relocate the shooter monitors without being worried about interfering with the cable layout. It is a good option for ranges where mixed-distance shooting disciplines are taking place."

Wi-Fi

"Each TrueScore10 target is equipped with its own Wi-Fi module, therefore it is capable to communicate with the server through a wireless access point. This is a good solution for smaller shooting ranges with up to five lanes. In such a scenario, both the targets and shooter monitors are interconnected using a wireless connection. This is the most flexible of all network configuration options as it allows easy relocation of all target devices."

"The local area network and the networking equipment is specific for each shooting range. Such things as range layout, number of targets and other range specific characteristics should be taken into consideration when building your network. Our team is here to help you define the most suitable network connection for your range."

INTARSO TrueScore 10 Technology Description

"TrueScore10 electronic scoring target was designed for sports clubs and international shooting competitions. The target system can be easily adjusted to any training and competitive scenario. For use at a competition, a black roll can be added to the target system.

TrueScore10 electronic scoring target was designed for sports clubs and international shooting competitions. The target system can be easily adjusted to any training and competitive scenario. For use at a competition, a black roll can be added to the target system. "

With TrueScore10 you can always stay confident that the hit result shown on the shooters' monitor is absolutely true to what you have actually scored. Measurement is done by two high-speed cameras placed in the top corners of the target frame and a U-shaped diffused LED strip that creates an even light field across the whole measurement plane. When a bullet passes the frame, its location is captured by the cameras at a rate of 40,000 images per second. Such a high measurement rate captures the bullet several times as it passes through the frame. This eliminates any possible detection error and always provides the exact hit position. The cameras are located in the same plane and right in front of the aiming card so there are no parallax errors when shooting at an angle. Contact-free hit detection removes the need to buy, store and change consumables such as black paper rolls used in acoustic target systems and helps to keep the shooting area clean from any paper leftovers. Adjustable LED light allows to regulate the brightness of the aiming card to match the surrounding light conditions or to be set according to the shooters' preference to reduce strain on the eyes. The built-in brightness presets for ISSF and DSB will help to quickly reset the target light for competition use. The integrated TFT display provides information about the score. It also acts as a green/red light for the 10m timed pistol disciplines.
